پارامترهای رابط PON
- 1 GPON port
- Compliance with ITU-T G.984.2, ITU-T G.984.5 Filter, FSAN Class B+, SFF-8472
- Connector type - SC/APC
- Transmission media - fiber-optic cable SMF - 9/125, G.652
- Maximum operating distance - 20 km
- Transmitter: 1310 nm DFB Upstream Burst Mode Transmitter
- Data rate: 1244 Mbps
- Average Launch Power: +0,5..+5 dBm
- Spectral Line Width: 1 nm (-20 dB)
- Receiver: 1490 nm APD/TIA Downstream CW Mode Digital Receiver
- Data rate: 2488 Mbps
- Receiver Sensitivity: -28 dBm, BER≤1.0x10-10
- Receiver Optical Overload: -4 dBm
پارامترهای رابط LAN
- 4 ports of Ethernet 10/100/1000BASE-T (RJ-45)
پارامترهای رابط FXS
- 2 FXS ports
- SIP
- Audio codecs: G.729 (A), G.711(A/U), G.723.1
- Fax transmission: G.711, T.38
- Loop resistance up to 2 kΩ
- Supported dialing technologies: pulse and frequency (DTMF)
- Caller ID issuing
پارامترهای ماژول وایرلس
- Supported standards: 802.11 a/b/g/n
- MIMO 2x2
- Frequency range: 2400 ~ 2483.5 MHz
- Security: WEB; WPA/WPA2
کانال های عملیاتی
نرخ داده ای 1
- 802.11b: 1; 2; 5.5 and 11 Mbps
- 802.11g: 6, 9, 12, 18, 24, 36, 48 and 54 Mbps
- 802.11n: from 6.5 to 300 Mbps (from MCS0 до MCS15)
حداکثر توان خروجی فرستنده 2
- 802.11b (11 Mbps): 17 dBm
- 802.11g (54 Mbps): 15 dBm
- 802.11n (MCS7): 15 dBm
مدولاسیون
- IEEE 802.11b: DQPSK, DBPSK, CCK
- IEEE 802.11g: BPSC, QPSC, 16QAM, 64QAM, OFDM
- IEEE 802.11n: BPSC, QPSC, 16QAM, 64QAM with OFDM
رابط USB
- 1 USB 2.0 port - for USB device connection
استانداردهای مورد پشتیبانی
- ITU-T G.984.x - GPON
- ITU-T G.988 OMCI specification
- IEEE 802.1D
- IEEE 802.1Q
- IEEE 802.1P
ویژگی های عملیاتی
- Support for TR-069
- “Bridge” and “Router” (including virtual ones) operation modes
- Support for PPPoE (auto, PAP, MSCHAP and CHAP authorization)
- Support for IPoE (DHCP-client and static)
- DHCP server on LAN side
- Multicast traffic transmission via Wi-Fi
- DNS (Domain Name System)
- DynDNS (Dynamic DNS)
- UPNP (Universal Plug and Play)
- NAT (Network Address Translation)
- NTP (Network Time Protocol)
- QoS (Quality of Service)
- IGMP Snooping
- IGMP Proxy
- UPNP, SMB, FTP-alg, Print Server
- VLAN complying with IEEE 802.1Q
ویژگی های امنیتی
- Rate limiting per ports
- FEC coding
پیکربندی و مانیتورینگ
According to TR-142:
- remote management via OMCI
- Remote management via TR-069
- Local management via WEB/CLI
- Firmware updating via: OMCI, TR-069, HTTP, TFTP
پارامترهای فیزیکی و شرایط محیطی
- Dimensions - 187x120x32 mm, desktop case
- Power supply: external 12V/2A DC adapter
- Maximum power consumption: 15 W
- Operating temperature from +5 to +40 °С
- Operating humidity ≤ 80%
1 The maximum wireless data rate is defined according to IEEE 802.11n/ас standard. The real bandwidth can be different. Conditions of the network operation, environment, the amount of traffic, building materials and constructions as well as network service data can decrease the real bandwidth. The environment can influence on the network coverage range
2 The value of the maximum output power will vary according to the rules of radio frequency regulation in your country.
