رابط ها
- 10/100/1000BASE-T (RJ-45) - 24
- 10GBASE-R (SFP+)/1000BASE-X (SFP) - 4
- Console port RS-232 (RJ-45) - 1
عملکرد
- Bandwidth - 128 Gbps
- Throughput for 64 bytes1 - 95.2 MPPS
- Buffer memory - 1.5 MB
- RAM (DDR4) - 2 GB
- ROM (RAW NAND) - 512 MB
- MAC table - 16384
- ARP table2 - 2039
- VLAN table - 4094
- L2 Multicast groups - 2048
- SQinQ rules - 988 (ingress), 988 (egress)
- MAC ACL rules - 1966
- IPv4/IPv6 ACL rules - 1975/988
- L3 IPv4 Unicast routes3 - 4066
- L3 IPv6 Unicast routes3 - 1015
- L3 IPv4 Multicast (IGMP Proxy, PIM)3 routes - 2029
- L3 IPv6 Multicast (IGMP Proxy, PIM)3 routes - 505
- VRRP routers - 255
- Maximum size of ECMP groups - 8
- VRF number - 16 (including default VRF)
- L3 interfaces - 2032
- Link Aggregation Groups (LAG) - 32, up to 8 ports per LAG
- Quality of Sevice (QoS) - 8 egress queues per port
- Jumbo frames - 10240 bytes
- Stacking - 8 devices
ویژگی های رابط ها
- Head-of-line blocking (HOL) protection
- Back pressure
- Auto MDI/MDIX
- Jumbo frames
- Flow Control (IEEE 802.3X)
- Port Mirroring (SPAN, RSPAN)
- Stacking
ویژگی های جدول MAC
- Independent learning mode per VLAN
- MAC Multicast Support
- Configurable aging time of MAC addresses
- Static MAC Entries
- MAC Flapping
ویژگی های VLAN
- Voice VLAN
- IEEE 802.1Q
- Q-in-Q
- Selective Q-in-Q
- GVRP
ویژگی های Multicast لایه 2
- Multicast groups
- Static Multicast groups
- IGMP Snooping v1,2,3
- Host/port-based IGMP Snooping Fast Leave
- IGMP proxy-report
- IGMP authorization through RADIUS
- MLD Snooping v1,2
- IGMP Querier
- MVR
ویژگی های L2
- STP (Spanning Tree Protocol, IEEE 802.1d)
- RSTP (Rapid Spanning Tree Protocol, IEEE 802.1w)
- MSTP (Multiple Spanning Tree Protocol, IEEE 802.1s)
- PVSTP+
- RPVSTP+
- Spanning Tree Fast Link option
- STP Root Guard
- BPDU Filtering
- STP BPDU Guard
- Loopback Detection (LBD)
- ERPS (G.8032v2)
- Flex-link
- Private VLAN
- Layer 2 Protocol Tunneling (L2PT)
ویژگی های L3
- Static IP routes
- Dynamic routing protocols RIPv2, OSPFv2, OSPFv3, IS-IS (IPv4 Unicast), BGP4 (IPv4 Unicast, IPv4 Multicast)
- BFD protocols (for BGP)
- Address Resolution Protocol (ARP)
- Proxy ARP
- Policy-Based Routing (IPv4)
- VRRP
- Multicast dynamic routing protocols PIM SM, PIM DM, IGMP Proxy, MSDP
- ECMP Load Balancing
- IP Unnumbered
- VRF lite
ویژگی های Link Aggregation
- LAG groups creation
- LACP
- LAG Balancing Algorithm
- Multi-Switch Link Aggregation Group (MLAG)
ویژگی های IPV6
- IРv6 Host
- Dual-stack IРv6, IРv4
ویژگی های سرویس
- Virtual Cable Tester (VCT)
- Optical transceiver diagnostics
- Green Ethernet
ویژگی های امنیتی
- Protection against unauthorized DHCP servers (DHCP Snooping)
- DHCP option 82
- IP Source Guard
- Dynamic ARP Inspection
- sFlow
- MAC-based authentication, Port Security, Static MAC entries
- Port-based authentication IEEE 802.1x
- Guest VLAN
- DoS attack prevention
- Traffic segmentation
- DHCP clients filtering
- BPDU attack prevention
- NetBIOS/NetBEUI filtering
Access Control Lists (ACL)
- L2-L3-L4 ACL (Access Control List)
- Time-Based ACL
- IРv6 ACL
- ACL based on:
- Switch port
- IEEE 802.1p
- VLAN ID
- EtherType
- DSCP
- IP protocol type
- TCP/UDP port number
- User Defined Bytes
Quality of Service (QoS) and rate limiting
- QoS statistics
- Shaping, Policing
- IEEE 802.1р Class of Service
- Storm control for different traffics (broadcast, multicast, unknown unicast)
- Bandwidth management
- Strict Priority and Weighted Round Robin (WRR) scheduling algorithms
- Three marking colors
- ACL-based traffic classification
- ACL-based CoS/DSCP assignment
- Setting the IEEE 802.1p priority for management VLAN
- DSCP to CoS, CoS to DSCP remarking
- ACL-based VLAN assignment
- 802.1p, DSCP mark assignment for IGMP
ОАМ
- 802.3ah Ethernet Link OAM
- 802.3ah Unidirectional Link Detection
ویژگی های مدیریتی
- Configuration file download and upload via TFTP
- SNMP
- Command Line Interface (CLI)
- Web interface
- Syslog
- SNTP (Simple Network Time Protocol)
- Traceroute
- LLDP (802.1ab) + LLDP MED
- LLDP (IEEE 802.1ab)
- Access control – privilege levels for users
- Management ACL
- Management interface blocking
- Local authentication
- IP addresses filtering for SNMP
- RADIUS/TACACS+ client (Terminal Access Controller Access Control System)
- Telnet server, SSH server
- Telnet client, SSH client
- SSL
- Macrocommands
- CLI commands logging
- System log
- DHCP autoprovision
- DHCP Relay (IPv4 support)
- DHCP Option 12
- Debugging commands
- Traffic to CPU rate limiting
- Password encryption
- Password recovery
- Ping (IPv4/IPv6)
ویژگی های مانیتورینگ
- Interface statistics
- RMON/SMON remote monitoring
- IP SLA
- CPU utilization monitoring per task and per traffic type
- RAM monitoring
- Temperature monitoring
- TCAM monitoring
MIB
- RFC 1065, 1066, 1155, 1156, 2578 MIB Structure
- RFC 1212 Concise MIB Definitions
- RFC 1213 MIB II
- RFC 1215 MIB Traps Convention
- RFC 1493, 4188 Bridge MIB
- RFC 1157, 2571-2576 SNMP MIB
- RFC 1901-1908, 3418, 3636, 1442, 2578 SNMPv2 MIB
- RFC 1271,1757, 2819 RMON MIB
- RFC 2465 IPv6 MIB
- RFC 2466 ICMPv6 MIB
- RFC 2737 Entity MIB
- RFC 4293 IPv6 SNMP Mgmt Interface MIB
- Private MIB
- RFC 2021 RMONv2 MIB
- RFC 1398, 1643, 1650, 2358, 2665, 3635 Ether-like MIB
- RFC 2668 IEEE 802.3 MAU MIB
- RFC 2674, 4363 IEEE 802.1p MIB
- RFC 2233, 2863 IF MIB
- RFC 2618 RADIUS Authentication Client MIB
- RFC 4022 MIB for TCP
- RFC 4113 MIB for UDP
- RFC 3289 MIB for Diffserv
- RFC 2620 RADIUS Accounting Client MIB
- RFC 2925 Ping & Traceroute MIB
- RFC 768 UDP
- RFC 791 IP
- RFC 792 ICMPv4
- RFC 2463, 4443 ICMPv6
- RFC 4884 Extended ICMP for Multi-Part messages support
- RFC 793 TCP
- RFC 2474, 3260 Definition of the DS field in the IPv4 and Ipv6 headers
- RFC 1321, 2284, 2865, 3580, 3748 Extensible Authentication Protocol (EAP)
- RFC 2571-2574 SNMP
- RFC 826 ARP
- RFC 854 Telnet
- IEC 61850
1 Values are given for one-way transmission
2 For each host in the ARP table, an additional entry is created in the switching table
3 IPv4/IPv6 Unicast/Multicast routes share hardware resources
4 BGP protocol support is provided under the license
