پارامترهای رابط PON
- 1 GPON port
- Compliance with ITU-T G.984.2, ITU-T G.984.5 Filter, FSAN Class B+, SFF-8472
- Connector type — SC/APC
- Transmission media — single-mode optical fiber (SMF) — 9/125, G.652
- Maximum operating distance — 20 km
- Transmitter: 1310 nm DFB laser, burst mode
- Data rate: 1244 Mbps
- Average output power: +0.5..+5 dBm
- Spectral line width: 1 nm (-20 dB)
- Receiver: 1490 nm APD/TIA Downstream digital receiver, CW Mode
- Data rate: 2488 Mbps
- Receiver sensitivity: -28 dBm, BER≤1.0x10-10
- Receiver optical overload: -8 dBm
پارامترهای رابط LAN
- 1 port of Ethernet 10/100/1000BASE-T (RJ-45)
- 1 port of Ethernet 10/100BASE-T (RJ-45)
پارامترهای ماژول Wireless
- Supported standards: 802.11 b/g/n
- MIMO 2×2
- Frequency range: 2400–2483.5 MHz
- Security: WEP, WPA/WPA2
Data rate¹
- 802.11b: 1, 2, 5.5 and 11 Mbps
- 802.11g: 6, 9, 12, 18, 24, 36, 48 and 54 Mbps
- 802.11n: from 6.5 to 300 Mbps (from MCS0 to MCS15)
Maximum power of the transmitter2
- 802.11b (11 Mbps): 18 dBm
- 802.11g (54 Mbps): 16 dBm
- 802.11n (MCS7): 16 dBm
- 802.11n (MCS0): 18 dBm
Modulation
- IEEE 802.11b: DQPSK, DBPSK, CCK
- IEEE 802.11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
- IEEE 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
پارامترهای فیزیکی و شرایط محیطی
- Power supply: 12 V DC, 0.5 A adapter
- Maximum power consumption: 6 W
- Operating temperature range: from +5 to +40 °C
- Operating humidity: up to 80 %
- Dimensions (W × H × D): 147 × 24 × 110 mm, desktop case, wall mounting option
- Weight: 0.25 kg
استانداردها
- ITU-T G.984.x – GPON
- ITU-T G.988 OMCI specification
- IEEE 802.1D
- IEEE 802.1Q
- IEEE 802.1P
ویژگی های عملیاتی
- TR-069
- "Bridge" and "Router" (including virtual ones) operation modes
- PPPoE (auto, PAP, MSCHAP and CHAP authorization)
- IPoE (DHCP-client and static)
- DHCP server on LAN side
- Multicast traffic transmission via Wi-Fi
- DNS (Domain Name System)
- DynDNS (Dynamic DNS)
- UPnP (Universal Plug and Play)
- NAT (Network Address Translation)
- NTP (Network Time Protocol)
- QoS (Quality of Service)
- IGMP Snooping
- IGMP Proxy
- SMB, FTP-alg, Print Server
- Firewall
- VLAN in accordance with IEEE 802.1Q
ویژگی های امنیتی
- Rate limiting per port
- FEC coding
تنظیمات و نظارت
- In accordance with TR-142:
- remote management via OMCI
- remote management via TR-069
- Local management via WEB/CLI
- Firmware update via OMCI, TR-069, HTTP, TFTP
1 The maximum wireless data rate is defined according to IEEE 802.11n/ac standard. The real bandwidth can be different. Conditions of the network,
environment, the amount of traffic, building materials and constructions and network service data can decrease the real bandwidth. The environment can influence on the network coverage range as well.
2 The value of the maximum output power will vary according to the rules of radio frequency regulation in your country.
